Specifications
Panel Cabinet
⌄
| Pixel pitch (mm) | 1.86 |
|---|---|
| Panel dimensions (W*H. mm) | 320 × 480 × 46.5 |
| Panel resolution | 172 x 258 |
| Pixel weight (kg) | 1.85 |
Module
⌄
| LED type | Black SMD1515 |
|---|---|
| Module size (W*H, mm) | 320 × 240 |
Power
⌄
| Power consumption (max./avg., W/m²) | 320 / 107 |
|---|
Data
⌄
| Brightness (nit) | 500 |
|---|---|
| Refresh rate (Hz) | 3840 |
| Grayscale (bit) | 12 - 13 |
| Viewing angle (H/V, °) | 160 / 140 |
| Storage temperature (°C) | -40 ~ +60 |
| Operating temperature (°C) | -10 ~ +40 |
| Storage humidity (RH) | 10% ~ 85% |
| Operating humidity (RH) | 10% ~ 80% |
| IP rating | IP40 / IP21 |
Mounting
⌄
| Certificate | CCC, FCC, ETL, CE, RoHS |
|---|
