BLEND LED
Side view 1
Side view 2
Side view 3
Side view 4

Specifications

Data
Ingress Protection
Front IP65 (Module)
Aspect Ratio
16:9
Recommended Viewing Distance
≥1.2m
Calibration
Support brightness and chroma
Brightness Control
Manual/Automatic
Color Temperature
2,000K - 9,500K Adjustable
Viewing Angle
H160° / V160°
Brightness
Max 400-800nit (varies by different textures)
Contrast Ratio
Depends on Specific texture
Processing Depth
18bit
Refresh Rate
3840 Hz
Video Frame Rate
50/60Hz
Operating Temperature/Humidity
-10°C~+45℃/10-80% RH
Storage Temperature/Humidity
-40°C~+60°C/10-90% RH
Certification
ETL/FCC/CE/CB/RoHS2.0/CCC/CQC/Low Blue Light
LED Life Time
100,000 Hours
Module
LED Type Fully
flip chip COB
Module Size
150mm × 168.75mm
Mounting
Maintenance
Front
Environment
Indoor
Material
Die-cast Aluminum
Standard Mounting Configuration
Fixed
Power
Input Power <Max>*
Depends on Specific texture
Input Power <Typical>*
Depends on Specific texture
Input Voltage
100 - 240V (50/60Hz)
Input Power Frequency
50 & 60 Hz
Power Status
Diagnostic LEDs
Panel Cabinet
Pixel Pitch
1.25
Pixel Density
640,000pixels/m²
Pixels Per Panel
480 x 270 pixels
Panel Size
600mm × 337.5mm × 29.8mm
Panel Diagonal
27"
Panel Area
0.2025m²
Panel Weight
4.3 ± 0.3kg / panel
