LDT Series
Side view 1
Side view 2
Side view 3
Side view 4

Specifications

Panel Cabinet
Pixel Pitch
4mm
Pixel density (pixels/sq.m.)
62500 dot/m²
Cabinet Size (WxHxD)
960mm x 960mm x 133mm (With Back Cover)
Cabinet Weight (kg/panel)
26.5 kg
Working Temp/Humidity (C/RH)
-20°C ~ 50°C / 10% ~ 80%RH (No Condensation)
Module
LED Type
SMD1921
Module Resolution (W×H)
80 X 40 = 3200 Pixels
Module Size (WxH)
(W) 320mm × (H) 160mm
Mounting
Maintenance
Rear
Cabinet Material
Die-cast Magnesium
Certification
CE/CB/ROHS/EAC
Data
Ingress Protection
≤0.5mm
Planeness
IP65 (Front), IP54 (Rear)
Single-dot Brightness Calibration
Support
Brightness
5000~5500 cd/m²
Color Temperature
2000K ~ 9300K Adjustable
Beam Angle (Hor/Ver°)
160° / 140°
Brightness/Color Uniformity
≥98%
Contrast Ratio
5000:1
Frame Changing Frequency
60Hz
Refresh Rate
3840Hz
Processing Depth
12 ~ 14 Bit
Video Support
2K、4K
Life Span (hrs)
100000hrs
Storage Temp/Humidity (C/RH)
-20°C ~ 55°C / 10% ~ 85%RH (No Condensation)
Power
Input Power <Max>
675 W/m²
Input Power <Typical>
203 W/m²
Power Supply Input Voltage
AC90~132V/ AC186~264V, 47-63 (Hz)
