Lmini P Series
Side view 1
Side view 2
Side view 3
Side view 4

Specifications

Panel Cabinet
Pixel Pitch (mm)
1.5625
Pixels Per panel
384 * 216
Pixel density (pixels/㎡)
409,600
Panel Size (WxHxD)/ (mm)
600 x 337.5 x 39.75
Panel weight (kg/panel)
4
Module
Module Size (WxH)/ (mm)
150 x 168.75
Mounting
Panel Material
Die Casting Aluminum
Maintenance
Full Front
Panel installation
fix
Certifications
CCC/CQC
Data
Processing Depth(Bit)
13
Refresh Rate (Hz)
1920 ~ 3840 Hz
Driving Type
1/54
Signal Transmission Distance (m)
CAT5 cable: < 100 m; Single mode fiber: < 10 km
Brightness (cd/㎡)
600
Viewing Angle (°)
0 ~ 160
Contrast ratio
10000:1
Storage Temperature (°C)
-20~60
Operating Temperature (°C)
-10~40
IP rating (front)
IP54
Storage Humidity (RH)
10% ~ 90% non-condensing
Operating Humidity (RH)
10% ~ 90% non-condensing
LED Life Time (hrs)
100000
Power
AC Input Voltage (V)
AC:100V~240V (50~60Hz)
AC Input Power Max
70W/Panel; 350W/㎡
AC Input Power Ave
25W/Panel; 125W/㎡
