UGM Series
Side view 1
Side view 2
Side view 3
Side view 4

Specifications

Panel Cabinet
Pixel Pitch
2.9mm
Pixel Resolution
168 x 168 dots
Panel Size (W×H×D)
500mm x 500mm x 73mm
Pixel Density
112,896 pixels/m²
Panel Weight
6.8 kg
Module
LED Type
3-in-1 Black SMD
Module Size (W×H)
250mm x 250mm
Power
Input Power/Panel (Max.)
150 W
Input Power/Panel (Ave.)
50 W
Input Voltage
100 - 240 VAC
Input Power Frequency
50 - 60 Hz
Mounting
Maintenance
Rear
Standard Mounting Configuration
Hanging, Stacking
Environment
Indoor
Material
Die-cast Aluminum
Data
Refresh Rate
3,840 Hz
Brightness
800 cd/m²
Contrast Ratio
3,000:1
Ingress Protection
IP30
Operating Temperature/Humidity
-10°C to 45°C / 10% - 80% RH
Viewing Angle (H/V)
140° / 120°
