Specifications
Panel Cabinet
⌄
| Pixel Pitch | 4.8 mm |
|---|---|
| Panel Dimensions | 500mm * 1000mm * 87mm |
| Panel Weight | 12.5 kg/Panel |
| Panel Resolution | 104 * 208 pixels |
| Pixel Density | 43264 Pixel/sqm |
Module
⌄
| LED Type | SMD1921 |
|---|---|
| Module Size | 500 * 250 mm |
Power
⌄
| Power(max/ave.) | 600 / 200 Watts/sqm |
|---|
Data
⌄
| Brightness | 4000 Nit |
|---|---|
| Grayscale | 16384 Grade |
| Viewing Angle (H/V) | 140° / 110° |
| Ingress Protection | IP65 / IP54 |
| Drive mode | 1 / 7 |
Mounting
⌄
| Maximum Hanging | 10 Panels |
|---|
